Base Models

Quality is More Than What Meets the Eye

Cross Trailers proves the inside is just as important as the outside.
  • Tube frame walls, mains, ceiling standard - it's stronger
  • Electrolysis (corrosion) resistant design - for longer life
  • Fully enclosed wall for dust/water seal - better protects your cargo
  • Flat-top design - greater strength
  • 0.030 exterior aluminum - increased durability
  • 1 piece aluminum roof - to minimize leaks
  • All LED lights - more efficient and longer-lasting

We offer a wide variety of Options

Call us to find a dealer near you.

(574) 326-3974

(574) 326-3974
hibu-tm

The trailer is very well manufactured and good looking that's why I decided to become a dealer.

- Rob Indig

Color (Standard)
Color (Upgrade)
Wheels

4' Wide Single Axle Standard Specifications

  • 4 x 6 SA
    • Overall Length - 9' 1"
    • Width - 64"
    • Height - 67"
    • Interior Length - 6' 3"
    • Width - 45"
    • Height - 48"
    • Platform Length - 21"
    • Axles Spring Brakes Optional Frame - 2" x 3"
    • Tire Size - ST175 / 80R13
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 640
    • Hitch Weight (#) - 120
    • GVWR (#) - 2000
    • Payload Capacity - 1360
    • Rear Doors - SINGLE DOOR
    • Opening Width - 40"
    • Opening Height - 44 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 4 x 8 SA
    • Overall Length - 11' 1"
    • Width - 64"
    • Height - 67"
    • Interior Length - 8' 3"
    • Width - 45"
    • Height - 48"
    • Platform Length - 21"
    • Axles Spring Brakes Optional Frame - 2" x 3"
    • Tire Size - ST175 / 80R13
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 700
    • Hitch Weight (#) - 130
    • GVWR (#) - 2000
    • Payload Capacity - 1300
    • Rear Doors - SINGLE DOOR
    • Opening Width - 40"
    • Opening Height - 44 1/2"
    • Exterior - 0.030Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 3" Welded Tubular Steel Main Frame
    • 2" Coupler With A-Frame
    • 2000# Dexter Spring Axle With E-Z Lube Hubs
    • ST175/80R13 LRC Tires
    • 4 Way Flat Electrical Plug
    • 3/4" Dry Max Floor (24" O/C)
    • 3/8" Water-Resistant Walls (24" O.C.)
    • 0.030 Aluminum Exterior (Screwless-Standard)
    • Bright Aluminum Rear Header
    • Flat Top With Bright Corners and Rear Hoop
    • 1 Piece Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • Single Rear Door With Bar Lock
    • Clear 1000 Coated Door Hardware
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

5' Wide Single Axle Standard Specifications

  • 5 x 8 SA
    • Overall Length - 11' 10"
    • Width - 80"
    • Height - 79"
    • Interior Length - 8' 3"
    • Width - 57"
    • Height - 60"
    • Platform Length - 17"
    • Axles - Spring
    • Brakes - Optional
    • Frames - 2" x 3"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 1020
    • Hitch Weight (#) - 120
    • GVWR(#) - 2990
    • Payload Capacity - 1970
    • Rear Doors - RAMP
    • Opening Width - 52"
    • Opening Height - 56 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24” O.C.) - 3/4" Water-Resistant
    • Sidewalls (24” O.C.) - 3/8" Water-Resistant
  • 5 x 10 SA
    • Overall Length - 13' 10"
    • Width - 80"
    • Height - 79"
    • Interior Length - 10' 3"
    • Width - 57"
    • Height - 60"
    • Platform Length - 17"
    • Axles - Spring
    • Brakes - Optional
    • Frames - 2" x 3"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 1080
    • Hitch Weight (#) - 130
    • GVWR (#) - 2990
    • Payload Capacity - 1910
    • Rear Doors - RAMP
    • Opening Width - 52"
    • Opening Height - 56 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24” O.C.) - 3/4" Water-Resistant
    • Sidewalls (24” O.C.) - 3/8" Water-Resistant
  • 5 x 12 SA
    • Overall Length - 15' 10"
    • Width - 80"
    • Height - 79"
    • Interior Length - 12' 3"
    • Width - 57"
    • Height - 60"
    • Platform Length - 17"
    • Axles - Spring
    • Brakes - Optional
    • Frames - 2" x 3"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 1140
    • Hitch Weight (#) - 140
    • GVWR (#) - 2990
    • Payload Capacity - 1850
    • Rear Doors - RAMP
    • Opening Width - 52"
    • Opening Height - 56 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24” O.C.) - 3/4" Water-Resistant
    • Sidewalls (24” O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 3" Welded Tubular Steel Main Frame
    • 2" Coupler With A-Frame
    • 3500# Spring Axle With E-Z Lube Hubs
    • ST205 / 75R15 LRD Tires
    • 4 Way Flat Electrical Plug
    • 3/4" Water-Resistant Floor (24" O.C.)
    • 3/8" Water-Resistant Walls (24" O.C.)
    • 0.030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat-Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • Ramp Door w/ Flap
    • Clear 1000 Coated Door Hardware
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

6' Wide Single Axle Standard Specifications

  • 6 x 8 SA
    • Overall Length - 12' 4"
    • Width - 93"
    • Height - 92"
    • Interior Length - 8' 3"
    • Width - 69"
    • Height - 72"
    • Platform Length - 18"
    • Axles - Spring
    • Brakes - Optional
    • Frame - 2" x 3"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 1240
    • Hitch Weight (#) - 110
    • GVWR (#) - 2990
    • Payload Capacity - 1750
    • Rear Doors - RAMP
    • Opening Width - 64"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 6 x 10 SA
    • Overall Length - 14' 4"
    • Width - 93"
    • Height - 92"
    • Interior Length - 10' 3"
    • Width - 69"
    • Height - 72"
    • Platform Length - 18"
    • Axles - Spring
    • Brakes - Optional
    • Frame - 2" x 3"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 1360
    • Hitch Weight (#) - 150
    • GVWR (#) - 2990
    • Payload Capacity - 1630
    • Rear Doors - RAMP
    • Opening Width - 64"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4"Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 6 x 12 SA
    • Overall Length - 16' 4"
    • Width - 93"
    • Height - 92"
    • Interior Length - 12' 3"
    • Width - 69"
    • Height - 72"
    • Platform Length - 18"
    • Axles - Spring
    • Brakes - Optional
    • Frame - 2" x 3"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 1480
    • Hitch Weight (#) - 200
    • GVWR (#) - 2990
    • Payload Capacity - 1510
    • Rear Doors - RAMP
    • Opening Width - 64"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4"Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 6 x 14 SA
    • Overall Length - 18' 4"
    • Width - 93"
    • Height - 92"
    • Interior Length - 14' 3"
    • Width - 69"
    • Height - 72"
    • Platform Length - 18"
    • Axles - Spring
    • Brakes - Optional
    • Frame - 2" x 3"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2"
    • Curb Weight (#) - 1600
    • Hitch Weight (#) - 250
    • GVWR (#) - 2990
    • Payload Capacity - 1390
    • Rear Doors - RAMP
    • Opening Width - 64"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4"Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 3" Welded Tubular Steel Main Frame
    • 2" Coupler With A-Frame
    • 3500# Spring Axle With E-Z Lube Hubs
    • ST205/75R15 LRD Tires
    • 4 Way Flat Electrical Plug
    • 3/4" Water-Resistant Floor (24" O.C.)
    • 3/8" Water-Resistant Walls (24" O.C.)
    • .030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • 32" Econo RV Door
    • Ramp Door w/ Flap
    • Clear 1000 Coated Door Hardware
    • 12 Volt Dome Light With Wall Switch
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

6' Wide Tandem Axle Standard Specifications

  • 6 x 10 TA
    • Overall Length - 14' 4"
    • Width - 93"
    • Height - 93"
    • Interior Length - 10' 3"
    • Width - 69"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 1760
    • Hitch Weight (#) - 165
    • GVWR (#) - 7000
    • Payload Capacity - 5240
    • Rear Doors - RAMP
    • Opening Width - 64"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 6 x 12 TA
    • Overall Length - 16' 4"
    • Width - 93"
    • Height - 93"
    • Interior Length - 12' 3"
    • Width - 69"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 1880
    • Hitch Weight (#) - 215
    • GVWR (#) - 7000
    • Payload Capacity - 5120
    • Rear Doors - RAMP
    • Opening Width - 64"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4"Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 6 x 14 TA
    • Overall Length - 18' 4"
    • Width - 93"
    • Height - 93"
    • Interior Length - 14' 3"
    • Width - 69"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2000
    • Hitch Weight (#) - 265
    • GVWR (#) - 7000
    • Payload Capacity - 5000
    • Rear Doors - RAMP
    • Opening Width - 64"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4"Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 4" Welded Tubular Steel Main Frame
    • 2 5/16" Coupler With A-Frame
    • 3500# Spring Axles With E-Z Lube Hubs
    • ST205/75R15 LRD Tires
    • 4 Way Electric Brakes
    • Gel Cell Rechargeable Breakaway Kit
    • 7 Way Electrical Plug
    • 3/4" Water-Resistant Floor (24" O.C.)
    • 3/8" Water-Resistant Walls (24" O.C.)
    • .030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • 32" Econo RV Door
    • Ramp Door w/ Flap
    • Clear 1000 Coated Door Hardware
    • 12 Volt Dome Light With Wall Switch
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

7' Wide Single Axle Standard Specifications

  • 7 x 10 SA
    • Overall Length - 14' 4"
    • Width - 102"
    • Height - 93"
    • Interior Length - 10' 3"
    • Width - 81"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 1620
    • Hitch Weight (#) - 220
    • GVWR (#) - 3500
    • Payload Capacity - 1880
    • Rear Doors - RAMP
    • Opening Width - 76"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 7 x 12 SA
    • Overall Length - 16' 4"
    • Width - 102"
    • Height - 93"
    • Interior Length - 10' 3"
    • Width - 81"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 1780
    • Hitch Weight (#) - 235
    • GVWR (#) - 3500
    • Payload Capacity - 1720
    • Rear Doors - RAMP
    • Opening Width - 76"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 4" Welded Tubular Steel Main Frame
    • 2 5/16" Coupler With A-Frame
    • 3500# Spring Axles With E-Z Lube Hubs
    • ST205/75R15 LRD Tires
    • 4 Way Electric Brakes
    • Gel Cell Rechargeable Breakaway Kit
    • 7 Way Electrical Plug
    • 3/4" Water-Resistant Floor (24" O.C.)
    • 3/8" Water-Resistant Walls (24" O.C.)
    • .030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • 32" Econo RV Door
    • Ramp Door w/ Flap
    • Clear 1000 Coated Door Hardware
    • 12 Volt Dome Light With Wall Switch
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

7' Wide Tandem Axle Standard Specifications

  • 7 x 12 TA
    • Overall Length - 16' 4"
    • Width - 102"
    • Height - 93"
    • Interior Length - 12' 3"
    • Width - 81"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2080
    • Hitch Weight (#) - 260
    • GVWR (#) - 7000
    • Payload Capacity - 4920
    • Rear Doors - RAMP
    • Opening Width - 76"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 7 x 14 TA
    • Overall Length - 18' 4"
    • Width - 102"
    • Height - 93"
    • Interior Length - 14' 3"
    • Width - 81"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2220
    • Hitch Weight (#) - 275
    • GVWR (#) - 7000
    • Payload Capacity - 4780
    • Rear Doors - RAMP
    • Opening Width - 76"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 7 x 16 TA
    • Overall Length - 20' 4"
    • Width - 102"
    • Height - 93"
    • Interior Length - 16' 3"
    • Width - 81"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2360
    • Hitch Weight (#) - 290
    • GVWR (#) - 7000
    • Payload Capacity - 4640
    • Rear Doors - RAMP
    • Opening Width - 76"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 7 x 18 TA
    • Overall Length - 22' 4"
    • Width - 102"
    • Height - 93"
    • Interior Length - 18' 3"
    • Width - 81"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 4"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2710
    • Hitch Weight (#) - 310
    • GVWR (#) - 7000
    • Payload Capacity - 4290
    • Rear Doors - RAMP
    • Opening Width - 76"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 7 x 20 TA
    • Overall Length - 24' 4"
    • Width - 102"
    • Height - 93"
    • Interior Length - 20' 3"
    • Width - 81"
    • Height - 72"
    • Platform Length - 19"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6"
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2870
    • Hitch Weight (#) - 330
    • GVWR (#) - 7000
    • Payload Capacity - 4130
    • Rear Doors - RAMP
    • Opening Width - 76"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 4" Welded Tubular Steel Main Frame (2 x 6 18' & up)
    • 2 5/16" Coupler With A-Frame
    • 3500# Wide Track Spring Axles With E-Z Lube Hubs
    • ST205/75R15 LRD Tires
    • 4 Way Electric Brakes
    • Gel Cell Rechargeable Breakaway Kit
    • 7 Way Electrical Plug
    • 3/4" Water-Resistant Floor (24" O.C.)
    • 3/8" Water-Resistant Walls (24" O.C.)
    • .030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • 32" Econo RV Door
    • Ramp Door w/ Flap
    • Clear 1000 Coated Door Hardware
    • 12 Volt Dome Light With Wall Switch
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

8' Wide 3500# Alpha Series (12' to 14') Specifications

  • 8.5 x 12 TA
    • Overall Length - 14' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 12' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2500
    • Hitch Weight (#) - 170
    • GVWR (#) - 7000
    • Payload Capacity - 4500
    • Rear Doors - RAMP
    • Opening Width - 90.5"
    • Opening Height - 74"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 14 TA
    • Overall Length - 18' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 14' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2690
    • Hitch Weight (#) - 170
    • GVWR (#) - 7000
    • Payload Capacity - 4310
    • Rear Doors - RAMP
    • Opening Width - 90.5"
    • Opening Height - 68 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 6" Welded Tubular Steel Main Frame
    • 2 5/16" Coupler With A-Frame
    • 3500# Spring Axles With E-Z Lube Hubs
    • ST205/75R15 LRD Tires
    • 4 Way Electric Brakes
    • Gel Cell Rechargeable Breakaway Kit
    • 7 Way Electrical Plug
    • 3/4" Water-Resistant Floor (16" O.C.)
    • 3/8" Water-Resistant Walls (16" O/C)
    • .030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • 46" Econo RV Door & Stepwell (32" on 8x12)
    • Rear Ramp Door with 4' Beavertail (3' on 16' to 20')
    • 4-Recessed D-Rings
    • Clear 1000 Coated Door Hardware
    • 2 - 12 Volt Dome Light With Wall Switch
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

8' Wide 3500# Alpha Series (16' to 24') Specifications

  • 8.5 x 16 TA
    • Overall Length - 20' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 16' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 2880
    • Hitch Weight (#) - 170
    • GVWR (#) - 7000
    • Payload Capacity - 4120
    • Rear Doors - RAMP
    • Opening Width - 90.5"
    • Opening Height - 74"
    • Opening Height w/Beavertail - 78"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 18 TA
    • Overall Length - 22' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 18' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 3070
    • Hitch Weight (#) - 190
    • GVWR (#) - 7000
    • Payload Capacity - 3930
    • Rear Doors - RAMP
    • Opening Width - 90.5"
    • Opening Height - 74"
    • Opening Height w/Beavertail - 78"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 20 TA
    • Overall Length - 24' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 20' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 3260
    • Hitch Weight (#) - 210
    • GVWR (#) - 7000
    • Payload Capacity - 3740
    • Rear Doors - RAMP
    • Opening Width - 90.5"
    • Opening Height - 74"
    • Opening Height w/Beavertail - 78"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 22 TA
    • Overall Length - 26' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 22' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 3450
    • Hitch Weight (#) - 250
    • GVWR (#) - 7000
    • Payload Capacity - 3550
    • Rear Doors - RAMP
    • Opening Width - 90.5"
    • Opening Height - 74"
    • Opening Height w/Beavertail - 78"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 24 TA
    • Overall Length - 28' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 24' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST205 / 75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 3640
    • Hitch Weight (#) - 270
    • GVWR (#) - 7000
    • Payload Capacity - 3360
    • Rear Doors - RAMP
    • Opening Width - 90.5"
    • Opening Height - 74"
    • Opening Height w/Beavertail - 78"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 6" Welded Tubular Steel Main Frame
    • 2 5/16" Coupler With A-Frame
    • 3500# Spring Axles With E-Z Lube Hubs
    • ST205/75R15 LRD Tires
    • 4 Way Electric Brakes
    • Gel Cell Rechargeable Breakaway Kit
    • 7 Way Electrical Plug
    • 3/4" Water-Resistant Floor (16" O.C.)
    • 3/8" Water-Resistant Walls (16" O/C)
    • .030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • 46" Econo RV Door & Stepwell (32" on 8x12)
    • Rear Ramp Door with 4' Beavertail (3' on 16' to 20')
    • 4-Recessed D-Rings
    • Clear 1000 Coated Door Hardware
    • 2 - 12 Volt Dome Light With Wall Switch
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

8' Wide 5200# Alpha Series (26' to 34') Specifications

  • 8.5 x 26 TA
    • Overall Length - 30' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 26' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST225/75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 4000
    • Hitch Weight (#) - 400
    • GVWR (#) - 9990
    • Payload Capacity - 5990
    • Rear Doors - RAMP
    • Opening Width - 90 1/2"
    • Opening Height - 74 1/2"
    • Opening Height w/Beavertail - 78 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 28 TA
    • Overall Length - 32' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 28' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" Tube
    • Tire Size - ST225/75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 4300
    • Hitch Weight (#) - 4300
    • GVWR (#) - 9990
    • Payload Capacity - 5910
    • Rear Doors - RAMP
    • Opening Width - 90 1/2"
    • Opening Height - 74 1/2"
    • Opening Height w/Beavertail - 78 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 30 TA
    • Overall Length - 34' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 30' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" 3/16" Tube
    • Tire Size - ST225/75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 4750
    • Hitch Weight (#) - 470
    • GVWR (#) - 9990
    • Payload Capacity - 5460
    • Rear Doors - RAMP
    • Opening Width - 90 1/2"
    • Opening Height - 74 1/2"
    • Opening Height w/Beavertail - 78 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 32 TA
    • Overall Length - 36' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 32' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" 3/16" Tube
    • Tire Size - ST225/75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 5050
    • Hitch Weight (#) - 490
    • GVWR (#) - 9990
    • Payload Capacity - 4940
    • Rear Doors - RAMP
    • Opening Width - 90 1/2"
    • Opening Height - 74 1/2"
    • Opening Height w/Beavertail - 78 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • 8.5 x 34 TA
    • Overall Length - 38' 4"
    • Width - 102"
    • Height - 102"
    • Interior Length - 34' 3"
    • Width - 95 1/2"
    • Height - 78"
    • Platform Length - 21"
    • Axles - Spring
    • Brakes - Electric
    • Frame - 2" x 6" 3/16" Tube
    • Tire Size - ST225/75R15
    • Hitch Ball Size - 2 5/16"
    • Curb Weight (#) - 5350
    • Hitch Weight (#) - 520
    • GVWR (#) - 9990
    • Payload Capacity - 4640
    • Rear Doors - RAMP
    • Opening Width - 90 1/2"
    • Opening Height - 74 1/2"
    • Opening Height w/Beavertail - 78 1/2"
    • Exterior - 0.030 Aluminum
    • Floor (24" O.C.) - 3/4" Water-Resistant
    • Sidewalls (24" O.C.) - 3/8" Water-Resistant
  • Specs
    • 2" X 6" Welded Tubular Steel Main Frame
    • 2 5/16" Coupler With A-Frame
    • 3500# Spring Axles With E-Z Lube Hubs
    • ST205/75R15 LRD Tires
    • 4 Way Electric Brakes
    • Gel Cell Rechargeable Breakaway Kit
    • 7 Way Electrical Plug
    • 3/4" Water-Resistant Floor (16" O.C.)
    • 3/8" Water-Resistant Walls (16" O/C)
    • .030 Aluminum Exterior (Screwless-Standard)
    • Bright Front Corners & Bright Rear Hoop
    • Flat Top With Bright Corners & Rear Hoop
    • Seamless Aluminum Roof
    • Brushed Aluminum Fenders
    • 24" Gravel Guard
    • 46" Econo RV Door & Stepwell (32" on 8x12)
    • Rear Ramp Door with 4' Beavertail (3' on 16' to 20')
    • 4-Recessed D-Rings
    • Clear 1000 Coated Door Hardware
    • 2 - 12 Volt Dome Light With Wall Switch
    • Exterior White Out L.E.D. Lighting
    • DOT Approved Lighting and Safety Equipment
    • Limited 5-Year Warranty

Learn More About

Cross Trailers

Play Video
Share by:
